Manufacturing context
Assunny Precision Circuits lists flexible PCB — published 2024 volume range in its official manufacturing documentation. FPC volume layer range: 2–8 layers, 2024 column. Production panel dimensions: 500 × 1200 mm, 2024 volume column. Minimum double-sided thickness: 0.06 mm, 2024 volume column. Inner-layer line / space: 0.03 mm; not a universal outer-layer limit. Dated 2024 volume-production column. RFPCB and small-batch ranges are separate. Ambiguously labelled copper/drill rows are excluded rather than repaired by inference. Which flex stack-up, stiffener arrangement and bend conditions are covered by the proposed manufacturing process?
Official company source reviewed- Manufacturing focus
- Flexible circuits · Battery-sensing interconnects · PCB and SMT services
- Published footprint
- Guangdong
- Listing and account
- Independently researched · factory account not claimed
Flexible PCB — published 2024 volume range
Manufacturer reportedDated 2024 volume-production column. RFPCB and small-batch ranges are separate. Ambiguously labelled copper/drill rows are excluded rather than repaired by inference.
- Layer count
- 2–8 layers
- Line / space
- Not disclosed for this profile
- Finished hole
- Not confirmed
- Impedance
- Not disclosed for this profile
| FPC volume layer range | 2–8 layers, 2024 column |
|---|---|
| Production panel dimensions | 500 × 1200 mm, 2024 volume column |
| Minimum double-sided thickness | 0.06 mm, 2024 volume column |
| Inner-layer line / space | 0.03 mm; not a universal outer-layer limit |
| Technical source | assun.net.cn · Manufacturer specification |
These are separate published limits, not a promise that every combination is manufacturable. Unknown values are excluded from numerical filtering.
Know what has been checked.
The website review establishes the source of a statement. Independent UL ownership, equipment and material checks are tracked separately.
UL ownership
Not independently verifiedNo supporting record has been reviewed for this category.
Qualification request: Legal holder, manufacturing address and current UL recognition.
Equipment & in-house processing
Not independently verifiedNo supporting record has been reviewed for this category.
Qualification request: Machine inventory, location and evidence that the relevant process runs at the quoted site.
Material traceability
Not independently verifiedNo supporting record has been reviewed for this category.
Qualification request: Laminate grade, supplier documentation and traceable production-batch records.
Sources & review record.
Reviewed 2026-09-21. Manufacturer pages can change; confirm the current revision when requesting a quotation.
- Assunny Precision Circuits — product and technical documentationhttp://www.assun.net.cn/zzll.aspx?nid=3&typeid=50002Source checked 2026-09-21Official website
- Assunny Precision Circuits — company informationhttp://www.assun.net.cn/about.aspx?nid=1&typeid=1Source checked 2026-09-21Official website
- Assunny Precision Circuits — company informationhttp://www.assun.net.cn/Source checked 2026-09-21Official website
- Assunny Precision Circuits — company informationhttp://www.assun.net.cn/products.aspx?nid=3&typeid=50020Source checked 2026-09-21Official website
Company names and images identify the source manufacturer. Listing does not imply endorsement, partnership, account participation or completion of a factory audit.
Make the first technical conversation useful.
Which flex stack-up, stiffener arrangement and bend conditions are covered by the proposed manufacturing process?
Attach the manufacturing brief
Layer stack-up, finished dimensions, copper weights, laminate grade, quantity and delivery destination.
Define acceptance
Finished-hole tolerance, impedance targets, coupon requirements, surface finish and permitted process substitutions.
Confirm the recipient
Agree the manufacturing legal entity, confidentiality terms and approved site before sharing production files.
