Manufacturing context
Mingxingda Electronics lists rigid PCB manufacturing — 1 to 12 layers in its official manufacturing documentation. Board thickness: 0.3–4.0 mm. Single / double-sided size: Up to 1200 × 600 mm. Multilayer size: Up to 400 × 600 mm. Base copper foil: 18, 35, 70 or 105 µm. Panel limits vary by construction. The source describes a drilled 0.20 mm hole, not an unambiguous finished-hole guarantee. Which stack-up, laminate grade, finished copper and acceptance criteria will be used for this board?
Official company source reviewed- Manufacturing focus
- 1–12-layer rigid boards · Copper-base thermal boards · Industrial and power PCBs
- Published footprint
- Hunan
- Listing and account
- Independently researched · factory account not claimed
Rigid PCB manufacturing — 1 to 12 layers
Manufacturer reportedPanel limits vary by construction. The source describes a drilled 0.20 mm hole, not an unambiguous finished-hole guarantee.
- Layer count
- 1–12 layers
- Line / space
- 0.1 / 0.1 mm
- Finished hole
- Not confirmed
- Impedance
- Not disclosed for this profile
| Board thickness | 0.3–4.0 mm |
|---|---|
| Single / double-sided size | Up to 1200 × 600 mm |
| Multilayer size | Up to 400 × 600 mm |
| Base copper foil | 18, 35, 70 or 105 µm |
| Technical source | mxdpcb.com · Manufacturer specification |
These are separate published limits, not a promise that every combination is manufacturable. Unknown values are excluded from numerical filtering.
Know what has been checked.
The website review establishes the source of a statement. Independent UL ownership, equipment and material checks are tracked separately.
UL ownership
Not independently verifiedNo supporting record has been reviewed for this category.
Qualification request: Legal holder, manufacturing address and current UL recognition.
Equipment & in-house processing
Not independently verifiedNo supporting record has been reviewed for this category.
Qualification request: Machine inventory, location and evidence that the relevant process runs at the quoted site.
Material traceability
Not independently verifiedNo supporting record has been reviewed for this category.
Qualification request: Laminate grade, supplier documentation and traceable production-batch records.
Sources & review record.
Reviewed 2026-09-21. Manufacturer pages can change; confirm the current revision when requesting a quotation.
- Mingxingda Electronics — product and technical documentationhttp://www.mxdpcb.com/about-30-1-4-4.htmlSource checked 2026-09-21Official website
- Mingxingda Electronics — company informationhttp://www.mxdpcb.com/about-2.htmlSource checked 2026-09-21Official website
- Mingxingda Electronics — company informationhttp://www.mxdpcb.com/about-7.htmlSource checked 2026-09-21Official website
- Mingxingda Electronics — company informationhttp://www.mxdpcb.com/Source checked 2026-09-21Official website
- Mingxingda Electronics — company informationhttp://www.mxdpcb.com/products-23-6-3-3.htmlSource checked 2026-09-21Official website
Company names and images identify the source manufacturer. Listing does not imply endorsement, partnership, account participation or completion of a factory audit.
Make the first technical conversation useful.
Which stack-up, laminate grade, finished copper and acceptance criteria will be used for this board?
Attach the manufacturing brief
Layer stack-up, finished dimensions, copper weights, laminate grade, quantity and delivery destination.
Define acceptance
Finished-hole tolerance, impedance targets, coupon requirements, surface finish and permitted process substitutions.
Confirm the recipient
Agree the manufacturing legal entity, confidentiality terms and approved site before sharing production files.
