MANUFACTURER DOSSIER

Zhejiang Zhen You Electronics Co., Ltd.

浙江振有电子股份有限公司 · Zhejiang

Official sources reviewed2026-10-08
ZHENYOU / SWITCH AND CONTACT CIRCUITS

Start with the contact system, then choose the interconnect.

Zhejiang Zhen You Electronics Co., Ltd. (浙江振有电子股份有限公司) makes printed circuits in Lin’an, Hangzhou. Its official introduction emphasizes carbon-film boards and conductive-paste interconnects for remote controls, appliance controllers and computer peripherals. Those are useful distinctions when sourcing a keypad or controller: the pressing contact and the connection between board faces are separate parts of the design.

The catalogue separates carbon-, silver- and copper-paste-filled boards from plated-through-hole double-sided boards. It also has single-sided and multilayer categories. This page follows four named constructions and the decisions they raise, rather than assigning one generic fine-line or hole limit to all of them. A buyer replacing a contact finish or hole process should approve the actual construction and its test plan, not just a visually similar panel.

Two decisions in your drawing

Define the carbon contact pattern, resistance and mating system. Separately define how the front and back conductors connect: plated copper or a specified conductive paste. Include both in the quotation revision.

PLATED ROUTE / ZY-PTH-002

Copper in the hole, carbon at the key.

Zhenyou original ZY-PTH-002 plated-hole catalogue panel
ZY-PTH-002 · The source pairs this complete panel image with its plated-through-hole description.

The ZY-PTH-002 detail explicitly describes copper plating connecting the two board faces, OSP surface treatment and carbon-ink key contacts. The original catalogue image is retained in full; its appearance does not disclose plating thickness, contact resistance or an approved application.

Release the hole and finish zones separately.

Specify drilled and finished diameters, annular-ring and plating acceptance, then identify the solderable OSP areas and the carbon contact artwork. Ask for the carbon overprint registration, deposit definition and inspection method. A plated hole is not a substitute for a contact-resistance test, and the carbon pattern does not establish the electrical rating of the hole.

The source presents carbon contacts as an alternative to gold contacts, but supplies no comparative lifetime or resistance dataset. For a change from gold to carbon, submit the mating contact material, force/travel and intended environment; agree a measurable qualification before changing the released assembly.

PASTE ROUTES / THREE NAMED EXAMPLES

Choose the paste recipe with the acceptance test.

The three detail pages describe filling holes with the named conductive paste and combining carbon film with OSP. They describe achieving interconnection like a plated-through-hole board; that statement does not establish identical resistance, current capacity or thermal endurance. Keep the recipe and the buyer’s required performance in the same order record.

Original Zhenyou ZY-CTH-001 carbon-paste catalogue panel
ZY-CTH-001 · Carbon-paste-filled board

Carbon paste

The catalogue names carbon-filled interconnects. Request the paste grade, hole-fill inspection and the acceptable resistance from one board face to the other. Keep that limit distinct from the resistance measured at the key contact.

Original Zhenyou ZY-STH-001 silver-paste catalogue panel
ZY-STH-001 · Silver-paste-filled board

Silver paste

The page names silver paste; it does not provide a formulation or qualification result. Ask for continuity and insulation test conditions, paste cure controls, and resistance before and after your agreed environmental exposure.

Original Zhenyou ZY-CPTH-001 copper-paste catalogue panel
ZY-CPTH-001 · Copper-paste-filled board

Copper paste

Copper paste is the specified hole material for this entry. Request the material/cure record, connection geometry, continuity criterion and required storage/assembly window. Do not relabel this route as an electroplated copper barrel.

The photographs identify catalogue constructions. None supplies a scale, minimum line/space, finished-hole size, carbon thickness, current rating or guaranteed operating lifetime. These values remain drawing-review items.

DRAWING HANDOFF / CONTACT TO ASSEMBLY

A release sheet for this type of board.

Contact interface
Key artwork and contact zones; mating material, operating force/travel, measurement fixture and the allowed contact resistance. Define wear/environment testing and the point at which resistance is evaluated.
Face-to-face connection
Name plated copper, carbon paste, silver paste or copper paste. Include hole dimensions and inspection, paste formulation/cure where applicable, continuity and insulation acceptance, and a defined coupon or sample plan.
Panel and assembly
Finished outline, locating features, panel rails/separation and assembly handling. Mark carbon, OSP, solderable pads and keep-out areas separately. Agree storage, packaging and the applicable soldering profile.
Change control
Record the artwork revision, laminate, ink/paste formulation and producing site. Require approval for substitutions; retain the first-article measurements and lot identification with the order.

Ask for an annotated drawing rather than a general “can make” answer. For a repeat order, carry forward the approved contact system and process revision; a new paste supplier or curing recipe deserves explicit review. A generic electrical-test pass is only useful when its netlist, conditions and acceptance correspond to this construction.

Prepare the complete fabrication brief →
IDENTITY / PROCESS BACKGROUND

Match the order to the Lin’an entity and site.

The issuer’s 2025 annual report identifies Zhejiang Zhen You Electronics Co., Ltd., stock code 839559 and registration code 9133018571953330XB. It lists 777 Fengting Road as the registered/office address. The current sales-contact page also uses Fengting Road, while the website footer retains 1128 Jinxi South Road. Ask which address produces your board and appears on the purchase order and inspection record; the two addresses should not be silently treated as one plant.

A relevant standards contribution.

The national standards platform lists Zhejiang Zhenyou among the drafting organizations for GB/T 45714.54-2025, the conductive-pastes part of the PCB-materials series, effective 1 December 2025. This independently recorded contribution is relevant to its paste-process focus. It is not certification of a catalogue board or proof that your formulation meets every requirement.

Process development and equipment scope.

The dated issuer report explains paste-filled double-sided connections and reports research on HDI blind-hole plating, micro-slot machining, multi-order HDI warpage/delamination, additive PCB printing and nano conductive copper ink. These are research topics, not a published production HDI order or guaranteed microvia size. For multilayer/HDI work, request the actual released stack and current volume process window.

The current equipment gallery labels entries only as manufacturing equipment, without machine names, model, quantity or plant assignment. The technical-detail page returned no content during this review. A production shortlist should therefore request the equipment/process route for the selected plated or paste-filled construction, the relevant inspection method and a dated lot record. No machine capability is inferred from an unlabelled photograph.

Sales contacts are published on the official contact page, separate from the issuer’s investor-relations contact. PCBVerified’s inquiry remains on-platform; the receiving entity, producing address and drawing acceptance should be agreed before the order is released.

SOURCE TRAIL

Sources behind this profile

Individually researched on 8 October 2026. Original catalogue photographs are linked to their named products; process descriptions, standards participation and dated issuer research are kept in their respective scopes.

  1. MANUFACTURER / COMPANYCarbon-film focus and named applications ↗
  2. MANUFACTURER / PLATED HOLESZY-PTH-002: plated copper, OSP and carbon key contacts ↗
  3. MANUFACTURER / CARBON PASTEZY-CTH-001 description and corresponding original catalogue photo ↗
  4. MANUFACTURER / SILVER PASTEZY-STH-001 named hole-fill construction ↗
  5. MANUFACTURER / COPPER PASTEZY-CPTH-001 named hole-fill construction ↗
  6. MANUFACTURER / EQUIPMENTGallery labels; no model or quantity disclosure ↗
  7. MANUFACTURER / CONTACTFengting Road sales contacts and separate footer address ↗
  8. NATIONAL STANDARDS PLATFORMGB/T 45714.54-2025: title, effective date and drafting organizations ↗
  9. ISSUER / 2025 ANNUAL REPORTIssuer original PDF, Eastmoney mirror: p5 entity; p22 paste process; p23 research ↗
